|Standard:||IEC 60383||Material:||Porcelain C-120|
|Metal Fittings:||Available||Voltage Level:||HV|
Wall Bushing Insulators,
Low Voltage Bushing
IEC standard capacitor bushing insulator color grey for LV, MV capacitors
We export big quantity of such bushings to European countries , American countries , most of customers are capacitor factories .
the bushing can be with hollow bolt or solid bolt , the bolt material can be brass or stainless steeel .
the connection conductor can be solid copper wire or flexible copper wire .
we offer many material options , there will be at least one options meet you requirements.
the bushing electrical level can be 110 BIL , 125 BIL , 170BIL, related applicalbe voltage level is 15kV ,27KV , 35 KV, 46 KV etc.
the HIVOLT capacitor bushings are mainly used for insulation parts for power capacitors .
it can provide excellent insulation performance and strong mechanical support .
the bushing has very low leakage rate , very high mechanical cantilever strength .
the product finish are very shinning , without any surface defects .
we do routine test on each bushings after production to sort defect units out .
the test items including water pressure test , cantilever load withstand test , torsional strength test etc.
we can also design and develop new models based on different end user's requirements.
